Modular Automated Inspection System
ZEISS ScanBox Series 5
Modular automated 3D inspection system for medium to large components.
Overview
ZEISS ScanBox Series 5 is a modular automated optical 3D inspection system designed for the digitisation and inspection of complex components up to 3,000 mm in size. Built around a flexible platform, it allows manufacturers to configure and upgrade the system according to changing production requirements while maintaining consistent, metrology-grade inspection performance. The high-load rotary table and spacious measuring volume make it well suited for large parts, assemblies, tooling, and airfoils.
The Series 5 portfolio includes two primary configurations:
Series 5 (Standard) – A modular inspection cell offering flexible layouts and upgrade options for manufacturers inspecting larger or more complex components.
Series 5 RC (Remote Control) – Incorporates a motorised sliding door for fully automated loading via a robot or customised feeding system. By eliminating manual part handling, Series 5 RC shortens cycle times, increases machine utilisation, and supports high-throughput serial inspection. It is particularly suited for applications requiring continuous automated production.
The Series 5 portfolio includes two primary configurations:
Series 5 (Standard) – A modular inspection cell offering flexible layouts and upgrade options for manufacturers inspecting larger or more complex components.
Series 5 RC (Remote Control) – Incorporates a motorised sliding door for fully automated loading via a robot or customised feeding system. By eliminating manual part handling, Series 5 RC shortens cycle times, increases machine utilisation, and supports high-throughput serial inspection. It is particularly suited for applications requiring continuous automated production.
modular inspection
large part inspection
high-throughput
airfoil inspection
Key capabilities
- Components up to 3,000 mm
- Modular & upgradeable
- High-load rotary table
- Standard & RC variants
See it in action
Watch the ZEISS ScanBox Series 5 in action
A short walkthrough of the system, its measurement workflow, and typical applications.
